Automatic Milk Powder Zip-lock Bag Fill Seal Packaging Machine

FOB Reference Price:Get Latest Price
US $8,000-40,000 / Set | 1 Set/Sets Food Filling and Sealing Packaging Machinery (Min. Order)
Supply Ability:
30 Set/Sets per Month Food Filling and Sealing Packaging Machinery
Port:
shangbai/ningbo china port
Overview
Quick Details
Type:
Packaging Line, Food Filling and Sealing Packaging Machinery
Condition:
New
Application:
Beverage, Chemical, Food, Medical
Packaging Type:
Bags, Pouch, Stand-up Pouch
Packaging Material:
Plastic, Wood
Automatic Grade:
Automatic
Driven Type:
Electric
Voltage:
380V 50HZ
Power:
2.2KW
Place of Origin:
Zhejiang, China (Mainland)
Brand Name:
ECHO
Model Number:
MR8-200R
Dimension(L*W*H):
L1340*W1580*H1950mm
Weight:
1500kg
Certification:
CE ISO
After-sales Service Provided:
Engineers available to service machinery overseas
Packaging Machine material:
food packing machine
Auto Premade bag Packing machine:
Rotary Packaging Machinery
Filling and Sealing Packaging Machine:
Food&vegetable Packaging Machine
CE Approved Fill-seal Machinery:
Auto Fill-seal Premade Pouch Machinery
Tomato Sauce Filling Machine:
Food Rotary Packaging Macheine
Installation:
7 days/Engineer
Warranty:
1 year
Machine Material:
SS304
Bag Material:
Laminated film premade bag
Packaging & Delivery
Packaging Details
The machine will be put desiccant and wrapping by film and plastic bags and then pack by Wooden Box for Food Filling and Sealing Packaging Machinery for Stand-up Bag
Delivery Time
about 60 days for Food Filling and Sealing Packaging Machinery

Automatic Milk Powder Zip-lock Bag Fill Seal Packaging Machine



 Characteristic:

1.Automatic rotary packing machine adopt precision indexing device and PLC to control each action and working station to make sure the machine is easy operate and doing accurate.



2.The speed of this machine is controled by frequency converter.So that It can adjust according to the specific material and pouch which you need to pack.



3.The bag width,length and type can be changed according to your demands in same machine. Changing different bag and different size is easy.(If you have different bag size and bag type,please consult your Contact Person ).Adjust size by one handle but button so that it can easy operate and fix.



4.The machine adopt safety door system,waster washing system,alarm system.If somebody open the machine door when the machine is running,the machine will alarm and stop.If the air pressure show abnormal,the machine will stop and alarm.(Any other alarm can check by the machine specification)



5.Automatic checking system can check bag situation,filing and sealing situation.

The system show 1: no bag feeding,no filling and no sealing.

                            2:no bag opening/open error,will no filling and no sealing

                            3.no filling,will no sealing



6.The packing materials loss low, what this machine is used the preformed bag pattern is prefect and has a high quality of the sealing part, this improved product specification.



7.Product or packing bag contact parts adopt stainless steel or other materials which accord with the food hygienic requirements, guarantee hygiene and security of the food.



8.With different filler,this model can pack liquid,powder,solid,granule,solid mix liquid...



MR8-200R Advantage



1.One wheel to adjust all stations for bag size

High speed packing machine MR8-200R can adjust 8 working station bag size by one wheel handle.It just need takes 8-15 munites and easy to do.The general model need adjust the station bag size one by one by hand and it need takes 15-25munites.MR8-200R can adjust 8 working station by one handle wheel.



2.Adopt import protractor

The protractor of MR8-200R adopt Taiwan Brand so that the accuracy of it is better than general model relatively speaking.



3.Small plate with base plate technology

The base plate of MR8-200R use whole plate plus small plate system. Because the base plate is formed once by cast iron,the plate can not be so flat.We add small plate which mill really flat onto the base plate.The devices install onto the small plate to avoid the shrinking,noise and become more stable.



4.Special drive system

About the transmission,the MR8-200R match just one shaft in the whole machine and concave and convex cam.Thus,the machine drive smoothly with low noise,stable and also prolong service life.



Model

MR8-200R

No. of working stations

Eight

Bags size

W:80~210mm  L:100~300mm

Filling Volume

5 – 2500g depending on type of products

Capacity

35~60bags/min for common bag

8-45 bags/min for zipper bag

(The speed depends on the product status and filling weight)

Total power consumption

2.5Kw

Machine Weight

Approx. 1,200 Kgs

Dimension

1140*1500*1560mm

Compress Air Requirement

0.4m ³/min Supply by user



Working Process:



Station 1         Bag feeding

Feed many pouches or bags in the bag magazine, our main bag magazine can move up and down, you can feed bags very easily when it moved down, and when it moved up, there are a mechanical arm with two vacuum caps will take bag up and then transmit it to the mechanical gripper on the rotary table.

Station 2        Date Printing (option)

Station 3        Open

To open zipper pouches from top and bottom with two sets vacuum caps.

Station 4        Filling production

There are an opening detection device insert into the open bag or pouch to expanding it and detect if it is open or not.No open no filling no sealing

Station 5        Buffer

Station 6        Sealing 1

Station 7        Sealing 2

Seal the second time to make the sealing more perfectly.

Station 8        Forming and output

To make the sealing stable and preventing from wrinkling with a couple of cold press, then output the finished production automatically.



Machine details:



1.Machine Bag Feeding Hand                                                         2.Date Printer







3.Bag bottom opening device                                                         4.Sealing bar







 5.Bag holder

CNC Center:





Bag Samples:




Packaging & Shipping

   The   Food Filling and Sealing Packaging Machinery will be filled with desiccant  all the part and packed by film preservative film firstly to avoid moist .Then The machine will be packed by plastic bag.Faninally,the whole machine will be packed by  composite material box .
